Size: 14''~24''

Nominal Pressure: PN10/PN16

Design Standard: API 609; GB12238

Body Flange Drilling: DIN 2501; ANSI 125/150; BS 4504;                                                JIS B2210; AS 2129; GB 17241.6

Top Flange: ISO 5211

Face to Face: ISO 5752; API 609; MSS SP-67; GB12221

Test Inspection: API 598; GB13927; EN 12266-1

Suitable Medium: Water, Sewage, Air, Oil, Salts, etc.

Operations: Lever, Worm gear, Electric Actuator and Pneumatic
